JL685A Aruba Instant On 1930 48G 4SFP/SFP+ Switch

Thông số kỹ thuật Aruba JL685A

Datasheet Aruba 48G 4SFP/SFP+ Switch (JL685A)
I/O Ports and Slots	– 48 Ports GE RJ-45 – 4 SFP+ 1/10GbE ports
Physical characteristics
Dimensions	17.42(w) x 11.12(d) x 1.73(h) in (44.25 x 28.24 x 4.39 cm)
Weight	6.91 lb (3.13 kg)
Hardware
CPU	ARM Cortex-A9 @ 800 MHz
Memory	512 MB SDRAM
Flash	256 MB flash
Packet buffer	1.5 MB
Performance
Switching capacity	176 Gbps
Throughput capacity	130.95 Mpps
100 Mb latency (Packet size 64B)	< 4.5 uSec
1000 Mb latency (Packet size 64B)	<2.2 uSec
10000 Mb latency (Packet size 64B)	<1.2 uSec
Environment
Operating temperature	32°F to 104°F (0°C to 40°C)
Operating relative humidity	15% to 95% @ 104°F (40°C)
Non-operating temperature	‑40°F to 158°F (‑40°C to 70°C)
Non-operating relative humidity	15% to 95% @ 140°F (60°C)
Max operating altitude	Up to 10,000ft (3.048 Km)
Acoustics	Power: 0 dB (no fan)
Electrical characteristics
Frequency	50Hz/60Hz
AC voltage	100 – 127 / 200 – 240 VAC
Current	.8/.5 A
Maximum power rating	36.9 W
Idle power	16.8 W
Safety	UL 60950-1; IEC 60950-1;EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1 UL 62368-1 Ed. 2; IEC 62368-1 Ed. 2; EN 62368-1:2014
Emissions	VCCI-CISPR 32, Class A; CNS 13438; ICES-003 Issue 6 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015 +AC:2016 / CISPR-32, Class A
Immunity	– Generic CISPR 24 / CISPR 35 – EN EN 55024:2010 / EN 55035:2017 ESD IEC 61000-4-2 – Radiated IEC 61000-4-3 – EFT/Burst IEC 61000-4-4 – Surge IEC 61000-4-5 – Conducted IEC 61000-4-6 – Power frequency magnetic field IEC 61000-4-8 – Voltage dips and interruptions IEC 61000-4-11 – Harmonics IEC 61000-3-2, EN 61000-3-2 – Flicker IEC 61000-3-3, EN 61000-3-3
Device Management	Aruba Instant On solution; Web browser; SNMP Manager
